GV3-ME

GV3-ME40 25-40A Motor Protection Switch - Reliable Safety

Ensure motor safety with the GV3-ME40 25-40A Motor Protection Switch. single magnetic circuit breaker is often used with thermal relay to obtain short circuit protection and overload protection.

Protection Type

Magnetic protection: prevent short circuit function
thermal magnetic protection: prevent short circuit, overload, phase absence and phase imbalance function
Advanced protection: motor blocking, long starting time, grounding fault protection

Share products to

Product Details

Specification	In(A) Rated current In(A)	The adjusting rage of commuting current	The cutting capacity for rated limit short circuit lcu,the cutting capacity for rated work short circuit lcs						The distance of arcs(mm)
			230/240V		400/415V		690V
			Icu(KA)	Ics(KA)	Icu(KA)	Ics(KA)	Icu(KA)	Ics(KA)
GV3M10	10A	6-10A	/	/	15	7.5	4	2	50
GV3M16	16A	10-16A			15	7.5	4	2	50
GV3M20	20A	14-20A			15	7.5	4	2	50
GV3M25	25A	16-25A			15	7.5	4	2	50
GV3M40	40A	25-40A			15	7.5	4	2	50
GV3M63	63A	40-63A			15	7.5	4	2	50
GV3M80	80A	56-80A			15	7.5	4	2	50

The action characteristic of breaker(GV2 Motor circuit breaker) when every phase load is in balance
The multiple of rated current	Starting state	Stipulated time	Due result	The temperature of ambient air
1.05	Cold state	t≥2h	No disjounting	+20℃±2℃
1.3	Hot state (rises up to the stipulated currentafter following the test of No 1)	t< 2h	Disjounting
10	Cold state	t< 2s	Disjounting

The action characteristic of breaker(GV2 Motor circuit breaker) when every phase load is in balance
The multiple of rated current		Starting state	Stipulated time	Due result	The temperature ofambient air
Any two phases	The third phases
1	0.9	Cold state	t≤2h	No disjounting	+40℃±2℃
1.15	0	Hot state (rises up to the stipulatedcurrent after following the test of No 1)	t< 2h	Disjounting

Here is a revised version of the product details for the GV3-ME40 25-40A Motor Protection Switch, ensuring that relevant keywords are used at least five times and pronouns are replaced with specific terms: The GV3-ME40 25-40A Motor Protection Switch is designed to offer reliable protection for motors operating within the 25 to 40 amp range. The GV3-ME40 Motor Protection Switch provides both thermal and magnetic protection, ensuring that motors are safeguarded from overloads and short circuits. By using the GV3-ME40 Motor Protection Switch, users can enhance the safety and longevity of their motors, reducing the risk of electrical damage.

The GV3-ME40 25-40A Motor Protection Switch is ideal for industrial applications where medium to large motors require dependable protection. The GV3-ME40 Motor Protection Switch features adjustable trip settings, allowing users to customize the protection based on the specific requirements of their motors. This flexibility ensures that the GV3-ME40 Motor Protection Switch can be used in a wide range of applications, including pumps, conveyors, and other heavy-duty equipment.

Installation of the GV3-ME40 25-40A Motor Protection Switch is straightforward, thanks to its compact design, which allows it to fit easily into existing motor control panels. The GV3-ME40 Motor Protection Switch is compatible with both single-phase and three-phase systems, making it versatile for different motor configurations. This compatibility ensures that the GV3-ME40 Motor Protection Switch can be integrated into various industrial setups without requiring extensive modifications.

In addition to providing overload and short circuit protection, the GV3-ME40 25-40A Motor Protection Switch also helps reduce maintenance costs by preventing motor damage due to electrical faults. The durable construction of the GV3-ME40 Motor Protection Switch ensures long-term performance even in demanding environments. This makes the GV3-ME40 Motor Protection Switch an essential component for any motor control system requiring robust protection.

By choosing the GV3-ME40 25-40A Motor Protection Switch, users can ensure that their motors are protected from electrical faults while maintaining efficient operation. The GV3-ME40 Motor Protection Switch not only enhances safety but also improves overall system reliability by minimizing downtime caused by electrical issues. For any application requiring motor protection within this current range, the GV3-ME40 Motor Protection Switch is a highly effective solution.

Questions & Answers

1.What is the current rating range of the GV3-ME40 Motor Protection Switch?

The GV3-ME40 Motor Protection Switch is designed for motors with a current rating range of 25 to 40 amps, making it ideal for medium to large motors.

2.How does the GV3-ME40 Motor Protection Switch safeguard motors?

The GV3-ME40 provides both thermal and magnetic protection, preventing motor damage from overloads and short circuits, ensuring reliable operation.

3.Can the GV3-ME40 be used in three-phase systems?

Yes, the GV3-ME40 Motor Protection Switch is compatible with three-phase systems, making it suitable for industrial applications requiring robust motor protection.

4.What types of applications are best suited for the GV3-ME40 Motor Protection Switch?

The GV3-ME40 is ideal for protecting motors in industrial machinery, pumps, conveyors, and other equipment that operates within the 25-40A current range.

5.Is the GV3-ME40 Motor Protection Switch easy to install in existing systems?

Yes, the compact design of the GV3-ME40 allows for easy integration into existing motor control panels without requiring additional components or extensive modifications.
